Electrical & Motor Specifications
- Voltage: 220 V
- Frequency: 50 Hz
- Phase: Single-phase
- Motor Power (P1): 1.1 kW
- Current (Intensity): 6.8 A
- Capacitor: 15 µF
- Number of Poles: 2
- Motor Type: Asynchronous
- Electrical Insulation Class: F
- Protection Rating: IPX5
Construction & Materials
- Pump Body: Stainless Steel AISI 304
- Impeller(s): Stainless Steel AISI 304
- Pump Shaft: Stainless Steel AISI 420
- Suction Body: Cast Iron
- Discharge Body: Cast Iron
- Diffuser(s): Technopolymer
Design & Manufacturing Features
- Number of Impellers: 4
- Suction Diameter: 1″
- Discharge Diameter: 1″
- Suction Connection Type: Threaded
- Discharge Connection Type: Threaded
- Seal Type: Mechanical Seal
- Motor Cooling: Fan-cooled
- On/Off Switch: No
- Plug Type: Without plug
Operating Limits
- Maximum Suction Lift: 2 m
- Maximum Water Temperature: 40 °C
Applications
- High-Pressure Water Supply
Ideal for multi-storey buildings, apartments, and commercial complexes requiring strong and consistent pressure. - Pressure Boosting Systems
Used in booster sets where higher head and flow are needed. - Agricultural & Irrigation Systems
Suitable for sprinkler irrigation, drip systems, and water distribution in farms. - Industrial Water Transfer
For clean water circulation in factories, processing units, and workshops. - Commercial Facilities
Hotels, hospitals, schools, malls, and office buildings.
