Motor & Power
- Motor Type: Single-phase induction motor with external ventilation and thermal protection.
- Rated Power: ~0.37 kW (0.5 HP) (~370 W).
- Voltage: 220-240 V AC, 50 Hz.
- Protection Class: IP44
- Insulation Class: Class B.
Hydraulic Performance
- Pump Type: Peripheral / vortex centrifugal pump designed for clean water without abrasive solids.
- Max Flow Rate: ~35 L/min
- Max Head: ~32–35 m (vertical lift).
- Typical Operating Range: ~1–27 m head for many versions.
- Max Suction Lift: ~8–9 m.
- Speed: ~2850 rpm.
Mechanical & Materials
- Pump Body: Cast iron
- Impeller: Brass peripheral impeller for high pressure.
- Shaft: Iron.
- Seals: Mechanical seal.
- Inlet/Outlet Size: 1″ × 1″ threaded connections.
Size & Weight
- Dimensions: ~290 × 145 × 175 mm (L×W×H).
- Weight: ~3 kg
Applications
- Household water pressure boosting and distribution.
- Garden, lawn, and greenhouse irrigation.
- Water transfer from tanks, wells, and small reservoirs.
- Cooling circulation and boosting clean water systems.
